A level TM-3000F Upper Pressure Vacuum Membrane Press Machine Introduction

TM3000F-P Vacuum Membrane Machine features a robust steel frame, 8 solid cylinders, and electric heating for precise and efficient operation. With a fast working speed of under 2 minutes, it ensures high-quality results, low energy consumption, and easy maintenance. Ideal for diverse manufacturers, it offers a daily productivity of 330-380 square meters in standard operation. High configuration and automatic functions make it a reliable choice for membrane pressing.
  • TM-3000F

  • ZHT

  • TM-3000F-P


Specification of TM3000F-P Vacuum Membrane Machine with PIN System

Technical Parameter:

· Dimensions: 12200mm×2480mm×2150mm

· Bed Dimension: 3000mm×1300mm

· Maximum Machining Height: 50mm

· Rated Working Pressure: Positive Pressure ≤ 0.6Mpa, Negative Pressure ≥ -0.095Mpa

· Total Power: 35Kw

· Actual Power Consumption: 12Kw (Save energy consumption more than 2 times)

· Total Weight: 19T

· Voltage: Three-phase 380v 50HZ

Hardware Configuration:

· Frame: Whole steel plate

· Number of Cylinders: 8

· Cylinder Diameter: 180mm

· Cylinder Structure: Solid

· Cylinder Stroke: 200mm

· Hydraulic System: Taiwan

· Heating System: Electric heating (nanotechnology)

· Vacuum Pump (Import): SV200

· Relay (Import): Schneider

Electrical Component List:

TM3000F-P -净版 副本


1. Fast Speed:

· The working period of both ordinary work-piece and highlight work-piece is less than 2 minutes.

· 2-4 times more efficient than common positive and negative pressure membrane pressure equipment.

2. Good Effect:

· The product processed by common film has a clear groove, no open side, no bubbling, no color difference.

· High-light working surface has strong adhesion, and the effect reaches the international leading level.

3. Low Energy Consumption:

· Total power of the machine is 35KW, half of that of peer equipment.

· Main heating starting power is 21KW, and the average power consumption is 12KW/h.

4. High Configuration:

· Key part of the machine adopts original parts from Germany, Japan, and Taiwan, which is high configuration and stable performance.

5. High Working Efficiency:

· The whole machine adopts automatic top block, saving the technological process of making the pad and the cost of process raw materials.

· Applicable to different manufacturers and different positive and negative pressure devices, reducing the cost of replacing equipment.

· Saves the scanning sequence of the pad of the equipment, improves working efficiency, and reduces labor cost.

· Requires only 3 workers: one trimming, one swinging board, and one placing panel.

6. High Productivity:

· Standard operation: 330-380 square meters/day.

· Non-standard operation: 210-250 square meters/day.


Equipment Maintenance:

· Every 3-6 months: Change vacuum pump oil once, and clean the filter every 15 working days.

How It Works:

· This machine adopts human-computer interface, easy to understand and operate, automatic double-station machine.

· Workbench rise up

· Add hydraulic pressure

· Warming

· Vacuum negative pressure

· Punch positive pressure

· Unloading positive pressure

· Unloading negative pressure

· Unloading hydraulic

· Workbench descend

· Flipped board sucking sample up

· This process is automatically completed by one click!

Silicone Plate Life:

· The silicone plate is imported from Korea and can be used for 3-4 months (about 1000 hours) and can be repaired (not covered by the warranty).

Energy Consumption:

· Main heating starting power is 38KW, and the average power consumption is 13KW/h.

· Dimensions: 13200mm2480mm2150mm

· Total Weight: 19T

· Working period: about 120 seconds after it enters the main machine.


1. Warranty period is one year, except for consumables.

2. Warranty does not include damage caused by human-made and natural disasters.

3. In case of equipment errors, the supplier provides free qualified parts and maintenance during the warranty period.

4. The supplier provides technical support for installation, debugging, and personnel training.


If you have any problems, please let us know.

Quality and service are the most important things for us.
