TM-2580C-Ⅱ
ZHT
Professional Mdf Cabinet Door Vacuum Membrane Press Machine
Introduction
It is used to work various high-profile PVC, hot transfer and single veneer
All kinds of PVC workpieces processed by this machine stick firmly, do not bounce off the edge.Line of groove is clear and in place.
Features
The key parts of hydraulic system adopt the import parts, the safe and reliable technology is excellent.
Vacuum pump imported from Germany, high horsepower, low fault rate.
The operating system adopts PLC to control large screen HMI, which is convenient to control, advanced in technology and high in automation.
Digital display current, voltage display, clear and intuitive.Microcomputer temperature control instrument is used for accurate temperature control.
Technical parameter
| Dimensions | 9930mm*2230mm*2150mm |
| Bed dimension | 2550mm*1270mm（inner diameter） |
| Maximum machining height | 50mm |
| Rated working pressure | positive pressure ≤0.6Mpa negative pressure ≥-0.095Mpa |
| Total power | 49.5KW |
| Actual power consumption | About 16KW |
| Total weight | 14T |
How it works
Preheating equipment
Put cabinet door on the workbench
Put cabinet door on the workbench
Pull the PVC membrane and cover cabinet door
Cutting membrane
Enter the host machine
The membrane floating up and heating
Vacuum plus negative pressure plus positive pressure
Release of positive and negative pressure
Unloading hydraulic
Drop workbench
Workbench out
Work end
Sample
Click here to contact Allison on Facebook Or E-mail Allison
Quality and Service are most important things for us
If you have any problem,please let us know
